Symmetry - 12 Volt Solar Panel - 10 Watts

$45.82



:

Description

10W Mono-Crystalline Solar Panel

Small area 12V PV module with.

36 cut cells in a 4x9 matrix connected in series. Robust and corrosion resistant aluminium frame with multiple mounting holes.

Features junction box (IP64) with 8 metre dual core fly lead.

5 year warranty on workmanship and 25 years on performance (min. 92% @ 12 years; min 85% @ 25).

Weight: 1.3 Kilograms
Warranty: 25yrs
Code: SOL-S10
Price: $45.82

Specifications

Symmetry - 12 Volt Solar Panel - 10 Watts
Rated Maximum Power (Pmax)10W
Power Tolerance0 ~ +3%
Voltage at Pmax (Vmp)18.47V
Current at Pmax (Imp)0.55A
Open-Circuit Voltage (Voc)22.63V
Short-Circuit Current (Isc)0.58A
Temperature Coefficent-0.40 %/°C
Maximum system voltage1000V DC
Dimensions (mm)335 x 235 x 25
Net weight1.2kg
ModelSY2-M10W-8M
ManufacturerSymmetry
